ACCU2016: Talk on Software Architecture Design 7: Perceiving Organising Principles

Posted on by

Perceiving Organising Principles requires us to develop a living and mobile thinking perception.

Unfortunately, as programmers, we are at a disadvantage.

We work in a domain where a lot of our thinking needs to be fixed into a rule-based structure in order to imagine how a computer program will function. This can have unwanted side effects of making it difficult to think in a mobile, living way. Multi-threaded programming demands this mobile thinking and is why it is so difficult.

At a personal level if we want to develop this other way of seeing we need to engage in some activities that foster that mobile mode of cognition. Perceiving livingness, almost by definition, requires that we need to handle ambiguity. This is what is required when we are working in the ‘gap’, or whenever we are dealing with human situations.

Logical thinking can cope with known and static issues, but as programmers we need to be very aware of the boundaries of our knowledge, more so than the lay person due to the inherent fixity of the domain of computer programming.

Alexander Revisited
At this point it is useful to look at some of Christopher Alexander’s ideas about the perception of beauty and links to what I have been saying about the idea of Cognitive Feeling.

Alexander started with defining a Pattern Language to help foster good architectural design – what he called Living Structure. This metamorphosed into his masterwork, The Nature of Order where he tried to get a better understanding of why we find certain structures beautiful.

In the Nature of Order, Volume 1 Chapter 5, he identified the following 15 properties of Living Structure:

  • Levels Of Scale
  • Strong Centres
  • Boundaries
  • Alternating Repetitions
  • Positive Space
  • Good Shape
  • Local Symmetries
  • Deep Interlock And Ambiguity
  • Contrast
  • Gradients
  • Roughness
  • Echoes
  • The Void
  • Simplicity And Inner Calm
  • Not-Separateness

If you just look at this as a list of items, it can be difficult to understand how these may be useful in design, apart from as heuristic guidelines. Although useful, if we look at them in the light of the dynamic concept of the Organising Principle, they make a lot more sense.

A major point is Alexander’s use of the word: Living. As I point out, this implies ambiguity. Therefore these 15 Properties can be seen instead as Organising Principles and when we try and ‘bring them down’ into a more fixed understanding we will only be seeing one way of looking at each one.

Perceiving the Organising Principle as a Disciplined Artistic Process.
In order to develop a mobile dynamic cognition that can better perceive Organising Principles, my thesis is that we need to take up some artistic pursuit in a disciplined and self-aware way. Do whatever appeals to you. For me I find painting and dance work well.

Lets look at how the practice of these pursuits parallels software development, or indeed any technical effort.

The following image is a watercolour painting of my daughter.

Princess

Freehand painting based on photo of my daughter.

This was one of my first forays into the world of painting and like the good novice artist I was, I decided to draw the picture first, using a photograph as a reference.

It took me 3 hours!

The first effort took 2 hours. The next took 1 hour and the last two each took half an hour, with the final result intended as the basis for the final painting. Being the worried novice that I was I decided to perform a ‘colour check’ painting freehand before doing the final version. In the end this became the final painting I have included here as I found that when I tried to paint into the final drawing it did not have the same life as the freehand painting.

This is an example of the difference between the ‘master’ freehand approach as compared to the ‘journeyman’ drawn approach. Of course I do not consider myself to be a master painter, but this example illustrates the self-developmental dynamic inherent in the artistic process.

We can also see here the need to do the foundational, ‘analytic’ work, in this case the drawing; followed by the ‘gap’ of putting the drawing away and using the freehand skill to come up with the ‘solution idea’.

The following is a painting by Jim Spencer and is for me an example of how less is more and illustrates how such minimalism is an essential aspect of any mastery. In this case Jim began learning art just after the second world war. (Also see my post Minimalist Mastery)

RedSkyAtNightSmall

The third example of and artistic pursuit is that of dance, in this case Argentine Tango. This particular dance is a form strongly founded on being far more conscious about what is a primary human activity: walking. (See my post on Dance as True Movement)

Here there is a need for structure, and a mobile process of interpretation and improvisation, both founded on a disciplined form of the dance. It can take years to learn how to ‘walk’ again but if followed in a disciplined manner can lead to sublime experiences of ‘Living Structure’ as the ‘team’ of two people dance from a common centre of balance.

In conclusion I hope you have been able to see the implicit link between Art and Technology and the value of balancing ourselves up as human beings.

Thank you for your attention.

In response to my statement about dancing John Lakos (author of Large Scale C++ Software Design) asked for some tango teaching at the end of the talk! The picture was taken by Mogens Hansen.

CharlesAndJohnTangoSmall

←ACCU2016: Talk on Software Architecture Design 6: Organising Principles

ACCU2016: Talk on Software Architecture Design 6: Organising Principles

Posted on by

I now want to try and explain the idea of an Organising Principle more clearly.

As an introduction they have a number of characteristics. They:

  • Embody a Living Wholeness.
  • Have a high degree of Ambiguity.
  • Are never Static.
  • Lie Behind the Parts.

ElanWoods

Embedded within a set of requirements is something that we need to find and embody in our implementation. As with high level schematics, there is a high degree of ambiguity surrounding this ‘something’.

During the talk we have moved from the high level schematics where I can hand wave to my hearts content about structure and architecture; down to diving into the depths of the actual implementation.

You may remember Andrei Alexandrescu’s keynote where he was talking about the details of a sort algorithm – first thing in the morning. Difficult after a late night before!

When trying to understand what he was talking about we are need to think at multiple levels:

  • Listen to the words he was saying.
  • Read through the code examples in his slides.
  • Imagine the dynamic behaviour of these code extracts.

In order to comprehend how this algorithm works dynamically, the listener needs to use their imagination at the same time as trying to understand what Andrei is saying. During this particular talk you could palpably feel the intense concentration in the whole audience.

During deep technical discussions listeners will work at these two levels of understanding:

  • The static code structure.
  • The dynamic behaviour of the static construct.

In addition one will only be looking at a single possible instantiation of a solution. There could be alternative ways of doing the same thing.

The term I like to use here is that during this process we are trying to ‘Livingly Think’ the Organising Principle.

An Organising Principle is NOT a static thing. It cannot be written down on a piece of paper. Although it informs the implementation it cannot be put into the code. If you fix it: You Haven’t Got It. Remember that phrase because getting it is the real challenge. It lives behind the parts of any concrete implementation.

I am explicitly using this separation of Whole and Parts, a discipline called Mereology. How can we understand the world in terms of wholeness and yet also see how the parts work therein?

Experienced people will have a sense of the whole and yet will be able to see where the likely risk points are going to be. They simultaneously see the whole picture and also know the essence of what needs to happen in the parts. This is what you pay for when you employ an expert. In my design example, for instance, an expert will know to ask about your allocation strategies and if they see some allocations going out of order they will point you at where you need to change the system.

Requirements implicitly contain Organising Principles.

They implicitly, not explicitly, embody dynamic specifications of what needs to happen. Much of my job when I talk to any customer is to try and understand:

  • What they want to do.
  • What I think can be built
  • How I can bring those together.

I need to understand what the core dynamic principles are that are embedded in their requirements. By definition if you are doing a useful piece of software the customer wont know what they actually NEED. They can talk about what they WANT, but that is based in their present experience. The conversation between the user and the developer will be generating new knowledge about future experience.

[Software development involves moving knowledge from the Complex to the Complicated domain as Cynefin defines it. This means we are dealing with emergent knowledge.]

Architecture references the Organising Principle.

If we take the point that an Organising Principle is not a fixed, discrete idea then we can see that it is much like comparing a film of an activity with its reality. The film is just a set of discrete frames, but the reality is continuous.

With software, the different architectures and implementations are different views of a specific Organising Principle. This is very hard to get our heads around and needs a far more mobile thinking than we normally use. This is the core of why good software development is so difficult.

Code is the precipitate of the Organising Principle.

If we manage to perceive this dynamic principle, referencing it by designing a software architecture that we embody into a specific code implementation, we are embarking on a process of precipitation. If we DON’T do this then – indeed – we only have a “Hopeful Arrangement of Bytes” as this talk title suggests.

Of course this may be a valid thing to do sometimes as a piece of ‘software research’ just to see how the code works out. This is especially relevant if there is a blank sheet, or ‘green field’ site where you just have to start somewhere. In this case you need to look at the part of the requirements that represent the riskiest aspects and just implement some proof of concept solution to check your understanding.

This is where it may not be an idea for a novice or journeyman programmer to follow the example of an experienced one.

Be warned: It is possible that a master programmer may be able to work at the keyboard and seemingly design as they go creating from internalized mature ideas. This is something that is definitely NOT recommended for inexperienced developers who will need to spend much more time maturing and externalizing their ideas first before those ideas become part of their ‘cognitive muscle memory’.

In the next and final post of the transcript of this talk I will deal with how to improve our perception of Organising Principles…

→ACCU2016: Talk on Software Architecture Design 7: Perceiving Organising Principles
←ACCU2016: Talk on Software Architecture Design 5: Active Design Ideas

ACCU2016: Talk on Software Architecture Design 5: Active Design Ideas

Posted on by

In the last post I highlighted some specific design problems and associated solutions. Now I want to look at these solutions a little more deeply.

To refresh our memory the solutions were as follows:

  1. Separating Mutex Concerns.
  2. Sequential Resource Allocation.
  3. Global Command Identification.

I want to characterise these differently because these names sound a little like pattern titles. Although we as a software community have had success using the idea of patterns I think we have fixed the concept rather more than Christopher Alexander may have intended.

I want to rename the solutions as shown below in order to expressly highlight their dynamic behavioural aspect:

  1. Access Separation.
  2. Sequential Allocation.
  3. Operation Filtering.

You might have noticed in the third example the original concept of “Global Command Identification” represents just one possible way to implement the dynamic issue of filtering operations. Something it has in common with much of the published design pattern work where specific example solutions are mentioned. To me design patterns represent a more fixed idea that is closer to the actual implementation.

Others may come up with a better renaming, but I am just trying to get to a more mobile and dynamic definition of the solutions. Looking at the issues in this light starts to get to the core of the issue of why it is so hard to develop an architectural awareness.

If you can truly understand, or ‘grok‘, the core concept of this characterisation, regardless of the actual words, you will see that they do not really represent design patterns – not in the way we have them at the moment.

This is where there is a difference between the architecture of buildings – where design patterns originated – and the architecture of software. Although both deal with the design of fixed constructs, whether it be the building or the code, the programmer has to worry far more about the dynamic behaviour of the fixed construct (their code). Yes – a building architect does have to worry about the dynamic behaviour of people inhabiting their design, but software is an innately active artefact.

Let me recap the debugging and design fixing process in terms of the following actions that are carried out in order:

1: Delicately Empirically Collect the Data.
Here we have to be very aware of the boundaries of our knowledge and collect information in a way that does not disturb the phenomenon we are looking at. Awareness of our own thinking process is vital here.

2: Imagine into the Problem Behaviour.
We have to imagine ourselves into the current behaviour that the system is exhibiting. (This is the hard bit when you are under pressure and is what requires a strong focus in order to understand what the existing design is doing)

3: Imagine into the Required Behaviour.
We need to imagine into what the required behaviour of the system NEEDS to be and it is here that we start to meet the ‘gap’ between problem and solution. It may indeed only need a one line fix, but quite likely there is a deeper design problem. Again here is a point where our self-awareness is important. Do we have the discipline to make ourselves stop and think more carefully and widely about the presenting problem?

4: THE GAP. Cognitively Feeling for the best Solution Concept.
In this stage there is a very fine “Cognitive Feeling” in action to decide what is a good fit to the problem. For the experienced programmer this is more than just a question of “Does this solution fit the requirement?”

There is the consideration of whether the proposed solution idea is going to be a sustainable fix during the future lifetime of the project.

This question is much like asking myself if I will still find
this painting beautiful in 10 years time.

YachtClubSmall

There is a current widely held belief that the best procedure for coming up with a design solution is to produce many possible alternatives and evaluate them in order to choose the best one. In practice I have found that this very rarely – if ever – happens.

I usually arrive at a single design solution by trying out the multiplicity of possible solutions while in the ‘gap’ where I am considering various alternatives – imagining each of them in operation, possibly ‘drawing’ the thoughts out on a whiteboard as I think.

In this part of the process the more experienced programmer will slow things down to the extent of even putting in a provisional simple solution that gives them some breathing, or thinking, space. This is the idea of provisionality mentioned by Marian Petre, because this mode of design thinking requires time and reduced pressure.

It is amazing how often this happens in the shower!

Of course this is predicated on the fact that I have done the required detailed groundwork, but as I mentioned in the poem, our logical thinking can only take us to the boundary of what we know. Trying to push to go faster results in inadequate and buggy designs that are based on immature thinking.

This is the central conundrum of software development. The more we dive down into detailed analysis, the more we encounter these ‘softer’, heuristic elements.

5: Implementation.
Finally we get to the implementation. As you will have seen it is far too easy to jump into “premature implementation”. It is hard, if not impossible, to teach people just how small a part the coding is of the whole process. It needs to be experienced. Until you have seen how a good design triggers an amazing collapse in code complexity, the importance of taking the time to search for that great design is not an obvious conclusion. This is a fundamental eye of the needle that all programmers need to go through.

This is the main reason I like programming:

I get less code.
I get something I can reason about.
I get something that does the job!

Beautiful!

In the next post I am going to show how the dynamic design solution ideas and the human analysis process link to what I will call the “Organising Principle”, a term I have borrowed from Rudolf Steiner’s lexicon.

→ACCU2016: Talk on Software Architecture Design 6: Organising Principles
←ACCU2016: Talk on Software Architecture Design 4: A Design Example

ACCU2016: Talk on Software Architecture Design 4: A Design Example

Posted on by

[The following transcript is more for the techies of my readership. For those of a less technical inclination, feel free to wait for the next post on “Active Design Ideas” which I have separated out due to the length of this post.]

I want to underpin the philosophical aspect of this discussion by using an example software architecture and considering some design problems that I have experienced with multi-threaded video player pipelines. The issues I highlight could apply to many video player designs.

The following image is a highly simplified top-level schematic, the original being just an A4 pdf captured from a whiteboard, a tool that I find much better for working on designs than using any computer-based UML drawing tool. The gross motor movement of hand drawing ‘in the large’ seems to help the thinking process.

Player

There are 3 basic usual commands for controlling any video player that has random access along a video timeline:

  • Show a frame
  • Play
  • Stop

In this example there is a main controller thread that handles the commands and controlling the whole pipeline. I am going to conveniently ignore the hard problem of actually reading anything off a disk fast enough to keep a high resolution high frame-rate player fed with data!

The first operation for the pipeline to do is to render the display frames in a parallel manner. The results of these parallel operations, since they will likely be produced out of order, need to be made into an ordered image stream that can then be buffered ahead to cope with any operating system latencies. The buffered images are then transferred into an output video card, which has only a relatively small amount of video frame storage. This of course needs to be modeled in the software so that (a) you know when the card is full; and (b) you know when to switch the right frame to the output without producing nasty image tearing artefacts.

These are all standard elements you will get with many video player designs, but I want to highlight three design issues that I experienced in order to get an understanding of what I will later term an “Organising Principle”.

First there was slow operation resulting in non real-time playout. Second, occasionally you would get hanging playout or stuttering frames. Third, you could very occasionally get frame jitter on stopping.

Slow operation
Given what I said about Goethe and his concept of Delicate Empiricism, the very first thing to do was to reproduce the problem and collect data, i.e. measure the phenomenon WITHOUT jumping to conclusions. In this case it required the development of logging instrumentation software within the system – implemented in a way that did not disturb the real-time operation.

With this problem I initially found that the image processing threads were taking too long, though the processes were doing their job in time once they had their data. So it was slowing down BEFORE they could get to start their processing.

The processing relied on fairly large processing control structures that were built from some controlling metadata. This build process could take some time so these structures were cached with their access keyed by that metadata, which was a much smaller structure. Accessing this cache would occasionally take a long time and would give slow operation, seemingly of the image processing threads. This cache had only one mutex in its original design and this mutex was locked both for accessing the cache key and for building the data structure item. Thus when thread A was reading the cache to get at an already built data item, it would occasionally block behind thread B which was building a new data item. The single mutex was getting locked for too long while thread B built the new item and put it into the cache.

So now I knew exactly where the problem was. Notice the difference between the original assumption of the problem being with the image processing, rather than with the cache access.

It would have been all too easy to jump to an erroneous conclusion, especially prevalent in the Journeyman phase, and change what was thought to be the problem. Although such a change would not actually fix the real issue, it could have changed the behaviour and timing so that the problem may not present itself, thus looking like it was fixed. It would likely resurface months later – a costly and damaging process for any business.

In this case the solution here was to have finer grained mutexes: one for the key access into the cache and a separate one for accessing the data item, which was then lazily built on first access.

Hanging Playout or Stuttering Frames
The second bug was that the playout would either hang or stutter. This is a great example because it illustrates a principle that we need to learn when dealing with any streamed playout system.

The measurement technique in this case was extremely ‘old school’, simply printing data to a log output file. Of course only a few characters were output per frame, because at 60fps (a typical modern frame-rate) you only have 16ms per frame.

In this case the streaming at the output end of the pipeline was happening out of order, a bad fault for a video playout design. Depending upon how the implementation was done, it would either cause the whole player to hang or produce a stuttered playout. Finding the cause of this took a lot of analysis of the output logs and many changes to what was being logged. An example of needing to be clear about the limits of one’s knowledge and of properly identifying the data that next needed to be collected.

I found that there was an extra ‘hidden’ thread added within the output card handling layer in order to pass off some other output processing that required. However it turned out that there was no enforcement of frame streaming order. This meant that the (relatively) small amount of memory in the output card would get fully allocated and this would give rise to a gap in the output frame ordering. The output control stage was unable to fill the gap in the frame sequence with the correct frame, because there was no room in the output card for that frame. This would usually result in the playout hanging.

MindTheGapCropped

This is why, with a streaming pipeline, where you always have limited resources at some level, allocation of those resources MUST be done in streaming order. This is a dynamic principle that can take a lot of hard won experience to learn.

The usual Journeyman approach to such a problem is just to add more memory, i.e. more resource! This will hide the problem because though processing will still be done out of order, the spare capacity has been increased and it will not go wrong until you next modify the system to use more resource. At this point the following statement is usually made:

“But this has been working ok for years!”

The instructions I need to tell less experienced programmers when trying to debug such problems will usually include the following:

“Do not change any of the existing functionality.
Disturb the system as little as possible.
Keep the bug reproducible so you
can measure what is happening.
Then you will truly know when you have fixed the fault.”

Frame Jitter on Stop
The third fault case was an issue of frame jitter when stopping playout. The problem was that although the various buffers would get cleared, there could still be some frames ‘in flight’ in the handover threads. This is a classic multi-threading problem and one that needs careful thought.

In this case when it came time to show the frame at the current position, an existing playout had to be stopped and the correct frame would need to be processed for output. This correct frame for the current position would make its way through to the end of the pipeline, but could get queued behind a remnant frame from the original stopped playout. This remnant frame would most likely have been ahead of the stop position because of the pre-buffering that needed to take place. Then when it came time to re-enable the output frame viewing in order to show the correct frame, both frames would get displayed, with the playout remnant one being shown first. This manifested on the output as a frame jitter.

One likely fix of an inexperienced programmer would be to make the system sit around waiting for seconds while the buffers were cleared and possibly cleared again, just in case! (The truly awful “sleep” fix.) This is one of those cases where, again due to lack of deep analysis, a defensive programming strategy is used to try and force a fix of what initially seems to be the problem. Again, it is quite likely that this may SEEM to fix the problem, and is likely to happen if the developer is under heavy time pressure.

The final solution to this particular problem was to use the concept of uniquely identified commands, i.e. ‘command ids’. Thus each command from the controlling thread, whether it was a play request or a show frame request, would get a unique id. This id was then tagged on to each frame as it was passed through the pipeline. By using a low-level globally accessible (within the player) ‘valid command id set’ the various parts of the pipeline could decide, by looking at the tagged command id, if they had a valid frame that could be allowed through or quietly ignored.

When stopping the playout all that had to be done was to clear the buffers, remove the relevant id from the ‘valid command id set’ and this would allow any pesky remaining ‘in flight’ frames to be ignored since they had an invalid command id. This changed the stop behaviour from being an occasional, yet persistent bug, into a completely reliable operation and without the need for ‘sleep’ calls anywhere.

In the next post I will recap the above process of finding and fixing the problems from a human development perspective.

→ACCU2016: Talk on Software Architecture Design 5: Active Design Ideas
←ACCU2016: Talk on Software Architecture Design 3: The Issue of Doubt

ACCU2016: Talk on Software Architecture Design 3: The Issue of Doubt

Posted on by

The next issue I want to explore is the central one of how we handle doubt. This is crucial in understanding how we come to know anything and so is pivotal in developing our own perception.

If we accept that there are problems with truly knowing reality, there are a number of ways of handling the situation.

One way to handle doubt is to decide that we cannot truly know anything and so should not even try. Just RUN AWAY! as the Knights of Arthur did from the rabbit in Monty Python’s Holy Grail! In this case we just fall back to perceiving the whole of the world without any analysis. This wish can particularly happen with the New Age movement where some people want to escape away from the world into a cloud of unknowing. But humans will always analyze their surroundings to some extent so this technique is rarely followed in reality.

A second way to handle doubt is by deciding that if we cannot truly know the world, all we need do is take a quick look at it and then come up with some hypothesized model. We then leave it to experimentation to tell us if we are right or wrong. In some areas of research, particularly anything to do with living processes, this means we will be disturbing the very processes we are looking at. It is like using the proverbial sledgehammer to crack the proverbial nut, and we know how that turns out for the nut in such a case! Scientific research can implicitly fall into this mode of operation, letting our thinking run ahead of the phenomena – a trap that Goethe highlighted.

I think that neither of these two modes of handling doubt really come to grips with improving how we generate knowledge about the world.

MindTheGapCropped

A more fruitful way is to learn to live with the gap in our knowledge, i.e. stay with the not knowing. This is a distinctly uncomfortable option and is very difficult in the world of commercial software development where we may have time and/or financial pressures. Despite not knowing the best way to solve a problem, we need to use the simplest implementation we can and realize that it is a provisional state, allowing us to return to it when our thinking has matured and we can see our way to a better solution. As Dr. Marian Petre mentioned in her keynote, this handling of ‘provisionality’ is a capacity that distinguishes the expert programmers from their less successful counterparts.

The Disciplined Self

As I mentioned at the end of the section on the path of the programmer, this requires the development of a strong sense of self. It requires that we maintain a disciplined practice when external pressures dictate that an immediate solution is required. We need to learn to hold a calm centre in the face of not knowing the right solution to a problem.

If we do not develop the ability to hold this centre we will not be able to think straight – a necessary function for our survival, commercial or otherwise.

→ACCU2016: Talk on Software Architecture Design 4: A Design Example
←ACCU2016: Talk on Software Architecture Design 2: The Historical Context

ACCU2016: Talk on Software Architecture Design 2: The Historical Context

Posted on by

[This is the second part of the transcript of my talk at ACCU2016 entitled: “Software Architecture: Living Structure, Art, or Just Hopeful Arrangements of Bytes“]

An enlightening aspect that surprisingly pertains to the issue of software design is the philosophical history that has led us to our current technological society.

Batalla_de_rocroi
Looking back we can see some origins in the Thirty Years War that took place between 1618 and 1648. Some commentators have drawn parallels with the impact of WW1 and WW2 between 1914 and 1945, saying that they could also be seen as a thirty year war. (See the book “Cosmopolis” by Steven Toulmin) The Thirty Years War of 1618 was a terrible war over much of Europe that resulted in the death of a third of the German population. It was a religious war between Protestants and Catholics, i.e. one religion – two factions – and raised serious concerns about the subjectivity of religious faith and the human condition. It was this that brought the quest for certainty to a head. The underlying question was: How can we be certain of what is happening in the world around us? And for the faithful in the 1600s, how can we be certain of God’s plan?

Descartes

It was during this time that René Descartes produced his “Discourse on Method” in 1637. He was the father of analytical geometry and of course coined the famous phrase “I think, therefore I am”. But this was predicated on the fact that we first doubt, thus the more correct phrase should be “I doubt, I think, therefore I am”. He concluded that because of our subjectivity, we cannot trust our senses and what they are telling us about the world, so he returned to the point of doubting. Since there was doubt, there must be a being that is doubting. This being, this ‘I’, that is doubting is thinking about this so therefore I am thinking. Since I am thinking I must exist in order to do that thinking.

Because the church was looking for certainty and because Descartes was able to couch his thought in terms that they could accept, this provided the foundation for the Scientific Revolution. This was followed by the Industrial Revolution which has led us to our current modern technological society. It is interesting to consider the fact that all that we take for granted today represents the end of 300 years or so of work based on Descartes’ philosophical premise: “I doubt, I think, therefore I am” where the aim was to try and eradicate subjectivity.

It is ironic that, although the aim was to be objective, his Cartesian coordinate system can be considered to be based on the structure of the human being! I stand up, and my head could be considered as the Y axis. I stretch my arms out to the side, there you have the X axis. I walk forward and there you have the Z axis.

This points to the difficulties that are implicit in the struggle to eradicate subjectivity – an objective (pun intended!) which I do not consider possible.

Kant

I usually refrain from mentioning Immanuel Kant since I am not a Kanitan scholar, but his thinking has formed much of the basis of modern thought. He produced the “Critique of Pure Reason” in 1781, and there is one quote I wish to highlight here from his considerable body of work. He said that “The world in itself is unknowable”. and this strengthened Descartes’ approach of not trusting our senses. It has given our modern scientific and technological society the excuse to allow our thinking to run ahead of the phenomena of the world.

This activity may sound familiar if you think back to the Path of the Programmer. It is a characteristic of the Journeyman phase.

With regard to my previous workshop on imagination, an area dealing with educating our subjectivity, it is interesting to see that one commentator, Mark Johnson, has noted that Kant had difficulty with imagination – Johnson states that he was “not able to find a unified theory of imagination in Kant’s writings” (The Body in the Mind p166).

Goethe

The third person I want to mention, and the one I feel most drawn to, is Goethe. It was Goethe who raised the warning flag to say that there was a problem with the underlying philosophy and practice of the scientific method. He pointed out that there was too much over-hypothesizing and that the thinking was going ahead of the phenomena of the world. Observation was not being given enough time.

This should ring alarm bells for any programmer because it is exactly what happens when someone takes an undisciplined approach to debugging.

Goethe, however, was particularly interested in understanding the growth of plant life. He wrote the Metamorphosis of Plants in 1788 and identified two very important activities. The first one is Delicate Empiricism (or “Zarte Empirie” in German), i.e. carefully collecting the data, carefully observing the world without overly disturbing its processes.

The second activity, which is what gave me the impetus to give my previous workshop on imagination in 2014, is Exact Sensorial Imagination. This is NOT fantasy, but exact, grounded imagination congruent with the observed phenomena. Goethe was trying to understand how plants grew and how their forms changed during growth.

For me this links to how software projects grow over time, as if they have a life of their own. A programmer needs to have a grasp of how the current software forms may change over time within such a context if they are to minimise future bugs.

The key difference between Descartes and Goethe is that Descartes was trying to eradicate subjectivity whereas Goethe was wanting to educate subjectivity.

The next important phase in philosophical thought is the advent of phenomenology in the 1900s. The realization that the process of coming to know something is crucial to, and as important as, the conclusion. Goethe is not considered a phenomenologist as he focused on specific phenomena rather than the philosophy behind what he was doing, but he definitely prefigured some of their ideas and so could be called a proto-phenomenologist.

We need to understand that phenomenology is a sea-change in philosophical thought. Here we are, living in a modern technological society based on 300 years of progress initiated by Descartes and his subject/object duality, and now the underlying foundational thinking has changed significantly.

The discipline of software development in the forefront of trying to understand what this change of thinking means in practice, though it may not have realised it. We need to understand how we develop our ideas and we need to understand our own cognitive biases, the subject of Dr. Marian Petre’s keynote “Balancing Bias in Software Development“. The point here is that we can do a certain amount in teams but there is also some personal work to do in understanding our own learning processes.

There is a wonderful quote by Jenny Quillien who has written a summary of Christopher Alexander’s Nature of Order books. She says in a preface:

“Wisdom tells us not to remain wedded to the products of thought but to court the process.”
(Jenny Quillien Delight’s Muse)

I think this is a lovely way of putting it. The process needs courting, it has to be done carefully as with Goethe’s Delicate Empiricism.

For those who wish to understand Goethe’s work and the philosophical issues around phenomenology, a primary source is Henri Bortoft. His writing is very understandable, particularly his book “Taking Appearance Seriously” and he draws on the work of Gadamer, one of the more recent phenomenologists.

→ACCU2016: Talk on Software Architecture Design 3: The Issue of Doubt
←ACCU2016: Talk on Software Architecture Design 1: The Path of the Programmer

ACCU2016: Talk on Software Architecture Design 1: The Path of the Programmer

Posted on by

[Following on from my introductory poem, this is the first of a series of posts providing a transcript of my talk at ACCU2016 entitled: “Software Architecture: Living Structure, Art, or Just Hopeful Arrangements of Bytes“. I have modified it to make it read better, cutting out the usual Ums and Errs!]

Introduction
The impetus for this talk came out of a chat I had with a friend, where I was ranting – as I can do – about code, and then realized that of course it is easy to rant about other people’s code. This prompted me to look back at my own experience. I started coding for a living back in 1980 – a fact that doesn’t bear thinking about! – and have spent most of my career implementing high data rate video editing systems. Until recently I worked in a company that does TV and film effects and editing systems, working on a large C++ system of more than 10MLOC. I have now moved into the CAE sector.

This is quite a ‘soft’ talk and I will be following on from some points in the keynote (Balancing Bias in Software Development) given by Dr. Marian Petre, although I will drop into some more grounded issues around video player pipeline design and some of the design issues that I have come across.

As I mentioned, I had a sense of frustration with the quality of what was getting produced in a commercial context, and frustration in terms of finding people who could make that switch from doing the actual coding and implementation to taking a more structural view. But though I started coding in 1980, it was not until 1995 that I can say I was actually happy with what I was producing. That is quite a sobering thought. OK, maybe I have the excuse that I did not really get into Object Orientation until 1985/6, and the Dreyfus brothers say it takes 10 years to become an expert in a domain, but even so…

I therefore want to delve into my own experience and try to understand why this takes so long. This is an issue, not so much about teamwork, but about what we could possibly do individually drawn from my own experiences with being a practitioner with large codebases.

In terms of my inspirations with regard to software architecture, Christopher Alexander of course is one, and there is one from left field. I got involved in starting a Steiner school for my children back in the 1990s and Steiner’s epistemology, drawn from a foundation coming from Goethe, is actually quite relevant.

ProgrammersPath

I will recap some of the points from my talk at ACCU2013 about “Software and Phenomenology”, and my workshop in ACCU2014 about “Imagination in Software Development”, but will be taking a slightly different slant on that content.

The Path of the Programmer

I want to start with some reflections on the path of the programmer as I have come to see it, borrowing an idea from Zen about the three phases on the path to enlightenment.

There is the initial NOVICE phase where you are still learning about the tools you have at your disposal.

Primary

A lot of your thinking is going to be Rule Based since you are learning the steps you need to take to do the job. The complexity of your thought is generally going to be less than the problem complexity you are dealing with when you get into ‘live’ industrial work, and hence you are producing brittle code, and/or it is not doing all that is needed. Here you are aware of your own limits because you know you do not know things, but you are unaware of your own process. I am not here talking about team development process, I am talking about your own personal learning process.

This level is thus characterized by an undisciplined self-awareness. There is little self-awareness about your own limits, and the lack of knowledge about your learning process means what awareness you have is undisciplined.

The next phase is what I call the dangerous phase, the JOURNEYMAN phase. It was about 1984 when I was in this phase.

Discus

Here you have a better knowledge of tools, having learnt about many of the programming libraries available to you. But the trap here is that the Journeyman is so very enamoured of those tools, and this conforms to the upward spike in the confidence curve that Dr. Marian Petre talked about this morning (The Dunning-Kruger effect).

Here the problem is that you can get into Abstract thinking and this can lead you to having an overly complex view of the solution. Your thinking here is more complex than the problem warrants. It is quite possible that up to 80% of the code will never be used. Therefore you are unaware of your own thinking limits and this can lead to an experience of total panic, especially if you are working on larger systems. [About a quarter of the listeners raised their hand when I asked if anyone had ever experienced this] This conforms to the downward spike that occurs after the upward spike on the confidence curve.

One anecdote I have is the story of one rather over-confident colleague who was given responsibility for a project. The evening before the client was due to turn up for a demo he was still coding away. When I came into work the next morning there was a note on his desk saying ‘I RESIGN’. He had been working through the night and didn’t manage to get to any solution. Of course the contract was lost.

This highlighted the total lack of awareness about his own limits. In this phase I too remember having an arrogant positivity – “its just software”, with the accompanying assumption that anything is possible. I had an undisciplined lack of self-awareness. Some people can stay in this phase for a long time, indeed their whole career and it is characterized by an insistence on designing and coding to the limit of the complexity of their thinking. This means, by definition, that they will have big problems during debugging because more complex thinking is needed to debug a system than was used in its creation.

We have gone here from one undisciplined state of partial self-awareness to another undisciplined state of no self-awareness. Of course this could be seen to be a bit of a caricature but you know if you hit that panic feeling – you are in this phase.

The next phase is the MASTER phase. In the past I have hesitated to call it the Master phase, referring to it instead as the Grumpy Old Programmer phase!

PetrelLand_4x3_2kcropped

Here we have a good knowledge of tools, but the issue that is different is that you will be using a Context Based thinking. You are looking at the problem you have got in front of you and fitting the tools to that problem. There is a strong link here with a practice when flying aircraft where you need to read from the ground to map, not the other way around. You must do it correctly because there have been a number of accidents where the pilots have read from the map to ground thus misidentifying their location.

It is the same with problem-solving. Focus on the problem, use the appropriate tools as you need them. It is interesting what Dr. Marian Petre said about how experts can seem as though they are novices – which is exactly what I feel like. Sometimes I look at my code and think “that doesn’t really look that complicated”. You bring out the ‘big guns’ when you need them, hopefully abstracted down under a good interface, but you know you need to keep the complexity down because there will be a lot of maintenance in the future, where you or others will have to reason about the code.

In this phase the software complexity is of the order of the problem complexity, perhaps a bit more because you will need a some ‘slack’ within the solution. At a personal level the major point here is that you are aware of your own limits because in the previous phase you have reached that panicked state.

One of the big things I have learnt through my career is the need to develop an inner strength and ability to handle this stressed state. For example there will be a bug. The client may panic. This is to be expected. The salesman may panic. Still possibly to be expected. As a developer if your manager panics too, you have a problem, because the buck will stop with you. Can you discipline your own thinking and your own practice so that you can calmly deal with the issue, regardless of how others are handling the situation? This is the struggle you can get in a commercial coding environment.

Implicit in this description is that you have developed a disciplined personal practice.

So in summary:

Novice

  • Rule-based thinking
  • Undisciplined
  • Some self-awareness.

Journeyman

  • Abstract thinking
  • Undisciplined
  • No (or very little) self-awareness.

Master

  • Contextual thinking
  • Disciplined
  • Deep self-awareness.

→ACCU2016: Talk on Software Architecture Design 2: The Historical Context
←ACCU2016: The Organising Principle

ACCU2016: The Organising Principle

Posted on by

ElanWoods
[This is the poem from my ‘Lightning Talk’ at ACCU2016. A transcript of the mentioned talk is to follow]

When you create
A system that you make
Does it ever get away

From you?

Get a life of its own.

IS IT ALIVE!
DON’T PANIC

Just Breathe.

Take a walk
Reflect
How did you get here?
Is it at all clear
What happened in that embedded, bifurcating moment
When you embarked
On your path.

Where did you STOP.

And think.

And really see the Pattern.
Did you really discern?

Or did you

fix it
kill it
force it
coerce it

Into preconceptions already held.
Driven by the money
Honey.

MindTheGapCropped
Did you savour the quiet moment of the mind
The gap between problem and solution?
Did you really see the living pattern?
Embedded in needs
That we call requirements.

Did you cherish Simplicity?
Or did you rush into Complexity?

So –

How can you change?
How can you learn?
To see the Essence.

The Organising Principle.

There is a way
A path you can take
But its not where you think
It out there – on the brink.

And its not a quick thing
An easy piece of mental bling.

Your Logic you see
Only takes you so far
To the edge of your knowledge.

But a way can be found
To cover the ground
On the far side of that edge.

But if you cannot see it.

DON’T PANIC

Just Breathe.

Take a walk
And if you wish
Come to my talk.

→ACCU2016: Talk on Software Architecture Design 1: The Path of the Programmer

ACCU2014 Workshop : Imagination in Software Development

Posted on by

A week ago on Saturday 12th April I facilitated a workshop at ACCU2014 on Imagination in Software Development which I am pleased to say – thanks to the participants – went very well.

Before the workshop I thought I had bitten off more than I could chew, having read through a lot of Iain McGilchrist’s book “The Master and His Emissary” and realising that using analytical thinking for such an exercise is very difficult. However thanks to my long suffering team at work giving me the chance to do a dry run, I was able to get feedback about what did and did not work and so ended up making some rather last minute changes. The final workshop format ended up being completely different to the dry run.

Before moving onto the exercises I gave a half-hour talk about the links between phenomenology; software; and brain hemisphere function, most of which in hindsight could have been left until after the exercises. My main objective, however, was to raise self-awareness about the participants’ internal imaginative processes.

I thought it would be good to highlight some of the primary ideas that came from the exercises, both in terms of the workshop’s preparation and its execution.

The need to get away from the software domain

The exercises in the workshop involved:

  • Listening to a story excerpt from a book.
  • Watching a film clip of the same excerpt.
  • Performing a software design exercise individually.

Each exercise was followed by discussions in pairs. It became abundantly clear that if you give a bunch of programmers a technical exercise, it will behave like a strong gravitational field for any ideas and it will be very difficult to get them to focus on process instead of content. Indeed during the workshop I had to interrupt the pair-based discussions to make sure they were talking about their own inner processes instead of the results of the design exercise I had given them! By reading a story and watching a film clip first it did make it easier to highlight this as a learning point since it was much easier to focus on internal process for the story and film clip.

Individual working instead of in small groups

The trial run with my team at work used small 3-4 person groups. I found that the team dynamics completely overshadowed their individual awareness. I therefore changed the format to make the core design exercise an individual process, followed by discussions in pairs. This had the desired effect of bringing their internal processes into sharper focus. The more you know about an area the more difficult it can be to “go meta” about it.

Some great insights from the participants

STORY
When listening to the story 3 processes were identified which occurred in parallel:

  • Visual – Picturing.
  • Emotional.
  • Logical – Probing.

FILM

  • The film was much more emotionally powerful, to the point of feeling manipulative.
  • But it was felt to be ‘weaker’ due to the imagery being concrete.

DESIGN

  • When performing the design exercise the ideas were experienced as a story, but as a sequential process rather than a parallel one.
  • The logical analysis required thoughts to be made explicit by writing them down otherwise it was hard to hold them in awareness.
  • There was a more conscious awareness of past experience affecting current ideas.
  • The initial analysis was wide-ranging followed by focussing down to the core ideas.

So if any of the participants make it to this page – I would like to say a great big thank you for getting involved.

Slide set follows:

Phenomenal Software: The Internal Dimension: Part 2b: Patterns & Livingness

Posted on by

In this post I am going to review Alexander’s three aspects of patterns mentioned before, namely:

  • The Moral Component
  • Coherent Designs
  • Generative Process

I will show how they link to the following ideas:

  • Freedom
  • Cognitive Feeling
  • Livingness

The Moral Component & Freedom

20110916_1352_BuzzardThe moral aspect of patterns can be approached from any of a number of ‘paths up the mountain’. Certainly Alexander was concerned about whether buildings were ‘nurturing’ for us to live in, and so was thinking about more than utility. With computer systems and applications it is easier to think that this utilitarian aspect is all that exists. But there is an environmental part – an inner environment of thought, or ‘theory’ as Naur would say, whether we be users or developers.

If we think about how tools extend our own faculties, indeed our own being, the importance of the quality of this inner environment takes on a new meaning. The nature of the tool will affect how we form our ideas, which in turn will influence the form of our externally made world. Thus Alexander’s use of the word ‘nurturing’ and its applicability to software is not so out of place as it initially seems.

We can relate the ideas of utility, environment and hence morality by considering the concept of freedom – but defined in terms relevant to computer use. A computer system or application is a tool to get a particular task done. Good tools are ‘transparent’, meaning that you do not notice them when performing a particular task – they ‘disappear’ from your consciousness and leave you ‘free’ to focus upon the task in hand. It is in these terms that we can speak about freedom when using computers.

If you experience this ‘transparency’ when using a computer, I would consider that the software you are using contains this moral component that Alexander has defined. To paraphrase his words from the ‘Mirror of Self’ question:

“‘Moral’ Software gives you the freedom to develop a better picture of the whole of yourself, with all your hopes, fears, weaknesses, glory, absurdity, and which – as far as possible – includes everything that you could ever hope to be.”

What higher statement of purpose could we have for the programs we write? The current prevalent economic vision of the software industry pales into insignificance against such a statement.

We should not forget that this freedom to develop a ‘better picture of the whole of ourselves’ can be experienced by both users and developers. Indeed it is a central tenet of my whole ‘Phenomenal Software’ series that good software developers are implicitly on a path of self development, whether they are conscious of it or not.

Coherent Design & Cognitive Feeling

PetrelWingIn talking about coherent design we need to remember that Alexander is dealing with the external world of objects and a software designer/developer is dealing with non-physical artefacts – the building architect works in an external world, the software architect works in an internal world – though no less real in its effects.

If we consider programming as an ‘internal art’ we can see how it can be difficult to communicate effectively about the ideas that underpin our design and coding. Peter Naur wrote about the need to maintain a theory alive in the minds of the programmers if a system was to be properly extended or maintained. He also noted that the theoretical element could not be communicated accurately via written documentation or even the code itself – it needed human interaction with people holding the living theory of the software.

Reflecting on my own career I have come to realize that it is difficult to identify an abstract form of coherence or goodness for software separate from the context in which it is to be used. For instance some code that I had found to be elegant in the early days of computing, say using little memory and having few instructions, would not be a good solution to the same problem in a modern context. So here we can see the integration required between form and function; solution and problem context. They need to be in harmony: coherent form in design will have the moral component in its function and will mean that the theories and meaning formed by the developer or user will make sense and meet the ‘Mirror of the Self’ needs.

Most novices will work from a set of rules, one such example being to ‘Make it Work, Make it Right, Make it Fast’ in that order. This is a valid heuristic useful to stop programmers optimizing the code too early. However a rule-based approach has the danger of separating the stages into individual parts – which is not the best way to proceed in one’s thinking. This is the same tension as that between the TDD (Test Driven Development) folks and the design-up-front folks – a classic example of the need to work from an integrated view of the whole and the parts – i.e. respectively: making it right and making it work; design-driven and test-driven. In practice being done together.

So over my career I have developed a feeling for good design in the crucible of solving real-world problems. In actuality I cannot make it ‘Work’ until I have a sense of what is ‘Right’, even to a small degree. You can perhaps see that I have a personal preference towards the design view, though during my work I can easily fall into the trap of hitting the keyboard too early, something I have worked vigorously at controlling! As I gained experience I started to get this sense of the best way to structure the software, and in some cases – such as perhaps designing a media player – I might have a feeling for what is ‘Fast’ at an early stage, but this needs to be kept strongly in check against reality. Optimisation should be based upon measurement and human beings can be worse than random at predicting what needs optimising.

This sense for a good or coherent design is what I have called a ‘cognitive feeling’ in an earlier post, which is a very fine and delicate sensation indeed – it is not strong emotion. Over the years of my career I liken its development to the creation of a new sense organ, cognitive in its nature. It can be difficult to explain to less experienced practitioners due to the fact that the sense is likely to have been implicitly developed over the years. However it matches closely to the feelings that are evinced by Alexander’s ‘Mirror of the Self’ test so that frequently when talking to more experienced developers it will not be hard to get to a commonality in judgement.

This means that in order to create coherent designs we will need to develop this extra sense of a fine cognitive feeling. A quote from Alexander serves to give an idea of this feeling sense, and though dealing with external geometric entities, the same comments relate to software design when imagining how the structures will function:

“A pulsating, fluid, but nonetheless definite entity swims in your mind’s eye. It is a geometrical image, it is far more than the knowledge of the problem; it is the knowledge of the problem, coupled with the knowledge of the kinds of geometrics which will solve the problem, and coupled with the feeling which is created by that kind of geometry solving that problem.” A Timeless Way of Building, Chapter 9.

Generative Process & Living Structure

CloudTrailIn Alexander’s talk at the OOPSLA’96 conference in San Jose, he seemed somewhat bemused by the software domain’s use of patterns. On reading Alexander’s Nature of Order series we can perhaps see why. Some of the central ideas are those of ‘living structure’ and ‘structure preserving transformations’ which result in a ‘generative process’. How could these relate to software?

It is easier to understand the concept of structure preserving transformations when looking at how living things grow. As they grow and develop they need to continue living – we cannot just take them apart, do some modifications, and then re-assemble them! Every step of growth cannot disturb their livingness – thus EVERY change must preserve their living structure. The world of living things has no choice but to use a generative process if it is to stay alive.

At first glance this does not relate at all to the built world. When fixing my car in my younger days, there were times when bits of gearbox and engine were all over the floor! If the car had been a living being it would have been dead, but since it was not I of course was able to re-assemble it and make it work. Small software systems are similar. However, if you have ever worked on a sizable legacy system you will know that you need to spend a LOT of effort on NOT breaking the system. Any changes you make need to be closer to structure preserving, and any bad structures will need major surgery to improve. In reality you will not even try if it is not economically viable. Once you have bad structure, or use a ‘structure destroying transformation’ it is extremely difficult if not impossible to remedy:

“Good transformations do not cause any upheaval. So to get a good project, we merely have to make a sequence of structure-preserving transformations. When we do so, a good design evolves smoothly, almost automatically.
However, even a single bad transformation can upset the smooth unfolding. If we make one transformation which destroys structure, in the middle of a sequence of good ones, things become ugly very quickly;” Nature of Order Book 2 p61. See also chapter 4.
I am not sure about the use of the word ‘merely’ in the above, since it understates the difficulty of identifying good transformations.

Also if we accept Naur’s Theory Building view and the idea of human mental schemas, this idea of a generative process makes more sense, since there is the living theory held by the programmers. If we then go further and connect to the phenomenological ideas of how we create meaning when we develop theories we can see that there is a justification for finding a livingness within the programming activity. Bortoft talks about the link between understanding and meaning which relates well to Naur’s ideas of theory building when understanding software. It also gives another dimension to the idea of livingness:

“understanding is the ‘concretion of meaning itself’, so that meaning comes into being in understanding.” Henri Bortoft in Taking Appearance Seriously p108

Just one final thought about the idea of livingness. Some might think that a running program would have a livingness, especially if it was a big system. I am not so sure and consider that it is WE who provide the livingness in the software domain. It is WE who create; experience design pain; judge. The computers are running a network of finalized thought constructs which is a different process to the thinking we do when defining those thought constructs. For me this perception of livingness in Alexander’s work and its relation to software is an ongoing work-in-progress.

I want to thank Jim Coplien for his help in pointing me at various ideas of Alexander that mesh with my work for this post.

In the next post I shall conclude this series of ‘Phenomenal Software’ by returning to the way philosophy has progressed forward from the Cartesian Subject/Object view. This will mean dealing with the thorny subject of subjectivity and of course you will have to decide if you can trust my judgements!

Thanks for reading.
